RoHS,ISO White cable LC SM Fiber Optic Pigtail with heat shrinkable tube

Detailed Product Description

Length:	3M	Cable Color:	White
Cable Diameter::	900um	Certificate:	RoHS,ISO
High Light:	fiber optics cable connectors, fiber optic fc connector



LC PC SM SX 0.9mm Fiber Optic Pigtails

Features:
4, 6, 8, 12, 24, 48 fibers optional
With heat shrinkable tube
Applicable connector: FC, SC, ST, LC…
Cable material: PVC, OM1, OM2 or OM3 optional
Single mode or multi mode
Cable size: Φ 0.9mm, Φ2.0mm, Φ3.0mm

Specifications (compliant with Telcordia and IEC standard):
Types: single mode, multi mode
Insertion Loss (dB): ≤ 0.2 (UPC) , ≤ 0.3 (APC)
Return Loss (dB): ≥ 50 (SM/UPC) , ≥ 60 (SM/APC), 35(MM/UPC)
Exchangeability: ≤ 0.2 dB
Tensile Strength: ≤ 0.2 dB ( 0 to15 Kgf )
Temp. Range: (- 40 to +80 degree centigrade)
Geometric Specification of Fiber Optic Patch Cords Finished End-face (fiber optic patch cord that passed Geometric test is of super performance) :
Types: PC Connector, APC Connector
Radius of Curvature: 10 to 25 mm, 5 to 15 mm
Apex Offset: ≤50 um, ≤100 um
Fiber Spherical Height: -90 nm , +50 nm
Angular Offset: 8°± 0.5°C (APC)



Parametor	Unit	Value
Connector Type		FC/UPC,FC/APC,SC/UPC,LC/UPC,LC/APC,ST/PC,MPO
Fiber Type		Multi-Mode	Single Mode
Insertion Loss	dB	Max.≤0.2	Max.≤0.3
Return Loss(Typ.)	dB	≥36(no APC connector)	/PC	/UPC	/APC
			≥45	≥50	≥60
Repeatability	dB	≤0.1
Interchangeability	dB	≤0.2
Connection Durability	times	≥1000
Operating/Storage Temperature	℃	-40~+80



Application:





1,FTTH , CATV, LAN, MAN, WAN, Test &Measuremen
2,Video transmission , Data transmission
3,Active Device Termination
4,Premise Installations
5,Telecommunication and Data processing Networks
6, Industrial, medical & military
7,Systems Integration for Long Haul, Metro and Access Network
